Sleeve Bearing, I.D. 1, L 1, PK3

This Bunting Bearings powdered metal bronze (SAE 841) sleeve bearing supports radial and axial loads. The bearing is formed and sintered, and then vacuum impregnated with SAE 30 oil that lubricates the bearing and shaft during rotation. It has a maximum load value of 2,000 psi (pounds per square inch), a maximum velocity value of 1,200 sfpm (surface feet per minute), and a maximum load-at-velocity (PV) value of 50,000. This plain bearing operates under temperatures ranging from 10 to 220 degrees F (-12 to +104 degrees C). Designed with a regular straight bore, this bearing is fits to conventional cylindrical shafts. This sleeve (plain) bearing is for use in various applications such as heavy-lifting equipment, pumps, aircraft, and motors, among others.Plain bearings (with no rolling elements) are used to handle radial or axial loads by providing a low-friction motion between two surfaces as shafts rotate or move back and forth through the center of the bearing. The most common types are bushings (also called bush), with a sleeve or flanged design, and are measured by their bore (inside diameter), outside diameter, length, and width (thickness). Plain bearings are used in automobiles, construction equipment, medical applications, railroad cars, turbines, various military applications, aeronautics, space exploration, among others.Bunting Bearings LLC manufactures a variety of bearings that meet standards for quality assurance established by the SAE, the American Society for Testing and Materials (ASTM), and the International Organization for Standardization (ISO), among others. Founded in 1907, Bunting Bearings LLC is based in Holland, Ohio.
